Rest assured when customizing high-quality Aluminum Alloy CNC Machined Components from Tuoyuan Metal. We carefully select premium materials and utilize mature, advanced processing technologies to precisely meet your industry-specific requirements.
Equipped with 25 professional CNC machining equipment, including 8 five-axis machining centers and 17 high-precision CNC lathes, combined with mature processing technology, we can achieve a machining precision of ±0.01mm for aluminum alloy components, with geometric tolerance controlled within ≤0.02mm and sheet metal bending accuracy reaching ±0.5°, which can accurately meet the dimensional requirements of precision assembly scenarios.
Our Aluminum Alloy CNC Machined Components covering two core categories: one is precision aluminum alloy CNC machined parts (turned parts, milled parts, complex contour parts), and the other is aluminum alloy structural assemblies (integrated machined assemblies, CNC welded assemblies), which can meet different processing needs from tiny precision accessories to large structural frames.
We have built an automated anodizing production line and a dust-free powder coating workshop, providing a variety of surface treatment services such as anodizing, sandblasting, and powder coating. According to the needs of application scenarios, we can customize surface effects with different colors, hardness, and corrosion resistance levels, taking both functionality and appearance into account.
We support customized processing based on 2D/3D drawings (CAD, STEP, IGS, etc.) and physical samples. A professional technical team follows up the whole process, providing one-stop service response from pre-technical communication and design for manufacturability (DFM) analysis to prototype trial production and mass production.
More than ten years of processing experience have accumulated a rich process database. The monthly production capacity can reach 500,000 precision machined parts, and the maximum load-bearing capacity of structural assemblies is 300kg. We can not only meet the needs of small-batch R&D and trial production but also undertake large-scale mass orders with stable and controllable delivery cycles.
Strictly adhering to ISO 9001:2015 and IATF 16949 system standards, we have established a three-level quality control process of "raw material inspection - in-process inspection - finished product full inspection". Professional testing equipment is equipped for key processes to ensure that the product defect rate remains at a low level, with stable and reliable quality.
Relying on large-scale procurement and lean production management, we effectively control production costs while ensuring machining precision and product quality, providing customers with cost-effective processing solutions. At the same time, we can optimize processes according to needs to further improve product performance adaptability.
Our technical team can provide DFM (Design for Manufacturability) optimization suggestions to help customers improve product structure and reduce processing difficulty; we also respond to customer problems in a timely manner during the after-sales phase and provide technical support to ensure the smooth progress of the entire cooperation process.
|
Product Category |
Specific Type |
Core Specification Parameters |
|
Precision Aluminum Alloy CNC Machined Parts |
CNC Turned Aluminum Parts |
Precision: ±0.01-0.03mm; Applicable Materials: 6061/6063/7075 aluminum alloy; Processing Range: Diameter 1-120mm, Length 5-600mm; Surface Roughness: Ra≤0.8μm |
|
CNC Milled Aluminum Parts |
Tolerance: ±0.01-0.04mm; Maximum Machining Size: 1200×1000×600mm; Processable Features: Multi-cavity, deep groove, curved surface structures |
|
|
Complex Contour Aluminum Parts |
Processable Features: 3D curved surfaces, irregular holes, stepped structures; Position Tolerance: ≤0.02mm; Applicable Scenarios: Precision matching components |
|
|
Aluminum Alloy Structural Assemblies |
Integrated Machined Assemblies |
Maximum Size: 2000×1500×800mm; Assembly Precision: ±0.05mm; Structural Strength: ≥180MPa; Application: Load-bearing frames |
|
CNC Welded Aluminum Assemblies |
Maximum Welding Size: 3000×1200×1000mm; Tensile Strength of Welds: ≥150MPa; Flaw Detection Qualification Rate: 100%; Welding Deformation: ≤0.3mm/m |
|
|
Surface-Treated Aluminum Alloy Parts |
Anodized Aluminum Parts |
Oxide Layer Thickness: 5-30μm; Hardness: ≥HV300; Salt Spray Test: ≥800 hours; Optional Colors: Natural, black, silver, etc. |
|
Powder-Coated Aluminum Parts |
Coating Thickness: 60-180μm; Adhesion: Grade 0; Impact Resistance: ≥60cm; Outdoor Service Life: ≥5 years |
|
|
Sandblasted Aluminum Parts |
Surface Roughness: Ra1.6-6.3μm; Uniformity: ≥95%; Application: Non-decorative structural parts |
